Product Details:
|
| Drive Mode: | 6x4 | Maximum Horsepower: | 300-400hp |
|---|---|---|---|
| Condition: | New | Segement: | Heavy Truck |
| Window: | Manual | Colour: | Option |
| Tires: | 12.00r22.5 | Design: | OEM, ODM |
| Steering System: | Left Hand Drive, Right Hand Drive, LHD, Rhd | Axle: | 4 Axle |
| Transport Package: | Naked Packing | Specification: | 8.2tons |
| Trademark: | Ouman | Origin: | China |
| Supply Ability: | 3000 | Customization: | Available |
| After-sales Service: | 1 Year | Warranty: | 1 Year |
| Catagory | Item | Unit | Parameter |
| Overall Parameter | Model | | G08K |
| Curb weight | kg | 14000 | |
| Max.total weight | kg | 25000 | |
| Outline dimension | (L×W×H) mm | 8935×2500×3890 | |
| Chassis | Chassis brand | | |
| Chassis model | | ZZ1257N3641W | |
| Steering position | | LHD | |
| Driving type | | 6×4 | |
| Wheel base | mm | 3625+1350 | |
| Tire | | 10.00R20 | |
| Power take-off | | Flywheel | |
| Engine | Model | | WD615.69 |
| Max.power | kW | 247 | |
| Displacement | L | 9.726 | |
| Drum system | Geometric volume | m³ | 13.6 |
| Agitating volume | m³ | 8 | |
| Max.diameter of drum | mm | 2280 | |
| Mixing drum length | mm | 4795 | |
| Slanting angle | ° | 15 | |
| Rotating speed | r/min | 0~14 | |
| Feeding speed | m³/min | ≥3 | |
| Discharge speed | m³/min | ≥2 | |
| Discharge residual rate | % | < 0.4 | |
| Slump scope | mm | 50~210 |
