Product Details:
|
| Model NO.: | Mixer Truck | Drive Mode: | 6x4 |
|---|---|---|---|
| Maximum Horsepower: | 300-400hp | Condition: | New |
| Segement: | Heavy Truck | Window: | Manual |
| Colour: | Option | Tires: | 12.00r22.5 |
| Design: | OEM, ODM | Steering System: | Left Hand Drive, Right Hand Drive, LHD, Rhd |
| Axle: | 4 Axle | Transport Package: | Naked Packing |
| Specification: | 8.2tons | Trademark: | Ouman |
| Origin: | China | Supply Ability: | 3000 |
| Customization: | Available | After-sales Service: | 1 Year |
| Warranty: | 1 Year |
| Catagory | Item | Unit | Parameter |
| Overall Parameter | Model | | G08K |
| Curb weight | kg | 14000 | |
| Max.total weight | kg | 25000 | |
| Outline dimension | (L×W×H) mm | 8935×2500×3890 | |
| Chassis | Chassis brand | | |
| Chassis model | | ZZ1257N3641W | |
| Steering position | | LHD | |
| Driving type | | 6×4 | |
| Wheel base | mm | 3625+1350 | |
| Tire | | 10.00R20 | |
| Power take-off | | Flywheel | |
| Engine | Model | | WD615.69 |
| Max.power | kW | 247 | |
| Displacement | L | 9.726 | |
| Drum system | Geometric volume | m³ | 13.6 |
| Agitating volume | m³ | 8 | |
| Max.diameter of drum | mm | 2280 | |
| Mixing drum length | mm | 4795 | |
| Slanting angle | ° | 15 | |
| Rotating speed | r/min | 0~14 | |
| Feeding speed | m³/min | ≥3 | |
| Discharge speed | m³/min | ≥2 | |
| Discharge residual rate | % | < 0.4 | |
| Slump scope | mm | 50~210 |
Liangshan Hongxiang Vehicle Manufacturing Co., Ltd. is located at the foot of the famous waterside Liangshan Mountain, close to the 220 National Road and Beijing-Kowloon Railway, the scenery is pleasant and the traffic is very convenient.
The company has a large number of professional production, technical personnel. Advanced production equipment, sophisticated technology, complete testing equipment. Our company is a set of production, scientific research, sales in one of the professional enterprises. The products reach or exceed the performance indicators of other similar products in China. Products mainly include: Various series of container transport vehicles, semi-trailer, van, full trailer, Shanghai 50, Tianjin 60, Dongfang Red 1000 full trailer, and undertake special vehicle modification, design business.
We insist on high-quality products to win the market, adhere to the sincere service to return customers, our pursuit is first-class equipment, first-class management, first-class technology, first-class products. We always adhere to the quality, low price, contract, keep faith, product implementation of "three guarantees", timely delivery, thoughtful service business purposes. Every step of development, the first thought is the user, we rely on the quality of survival, to the letter of development!
Contact Person: Mr. Xie
Tel: +86 13165184599
