Product Details:
|
| Tread: | 1820mm | Grade: | Heavy Duty |
|---|---|---|---|
| Types Of Suspension Systems: | Mac Pherson Type | Shape: | Van-type |
| Axle Number: | 2.3 | Tire Number: | 12 |
| Self-dumping: | Not Self-dumping | ABS Anti-lock Braking System: | No ABS Anti-lock Braking System |
| Material: | Steel | Condition: | New |
| Tire: | 12r22.5 | Landing Leg: | 28t, Two Speed, Manual |
| Axle: | 13t Axle | Size: | 13500X3000X1550 Mm |
| Product Name: | Low Bed Semi Trailer | Name: | Semi Trailer |
| Transport Package: | Container. Bulk Ship. RO-RO | Specification: | Please Consult Customer Service |
| Trademark: | Jin Rui | Origin: | Liangshan, Shandong Province, China |
| HS Code: | 8716399000 | Supply Ability: | 500 Set/Sets Per Month |
| Customization: | Available | After-sales Service: | 3 Yearplease Consult Customer Service |
| Warranty: | 1 Year |
| Type | |||
| External dimensions | 13000*3400*3800mm | ||
| Pallet size | 8500*3400*1250mm | ||
| curb weight | About 10000KG | sprung mass | 60000kg |
| specifications | |||
| suspension | 4-axis mechanical suspension(Customizable air suspension) | ||
| tire | 12R 22.5 16tires(Customizable) | ||
| Axls | 13T 2180 4pieces(Customizable) | ||
| Leaf spring | 90*16*10 8pieces | ||
| retardation | Brake wheel cylinder 6 pairs 2 singles | ||
| Climbing ladder | Spring assisted ladder | ||
| Leg | 28T | ||
| Relay Valve | Factory configuration | ||
| frame | |||
| Bodybeam configuration | The upper wing plate is 20mm, the lower wing plate is 20mm, and the belly plate is 12mm. Beam height 500mm | ||
| King PIN | 90#(Customizable) | ||
| Cargo platform | Bottom plate 4mm | ||
| Circuit and Painting | |||
| Light | LED: Rear tail combination lights, side marker lights, license plate lights, brake lights. | ||
| circuit | 24 volt 6-core circuit | ||
| Electrical connections | International standard pneumatic connector, 24V 7-pin socket | ||
| colour | Customizable | ||
