Truck Trailer 5 Axle 100 Ton 80 Ton Van Box Curtain Side Dump Trailer Van

Large Image : Truck Trailer 5 Axle 100 Ton 80 Ton Van Box Curtain Side Dump Trailer Van

Product Details:

Place of Origin:	China

Payment & Shipping Terms:

Delivery Time:	Peak Season Lead Time: one month, Off Season Lead Time: one month
Payment Terms:	LC, T/T, D/P

Contact Now

Truck Trailer 5 Axle 100 Ton 80 Ton Van Box Curtain Side Dump Trailer Van

Description

Types Of Suspension Systems:	Air Suspension	Shape:	Flatbed
Axle Number:	3/4	Tire Number:	16
Self-dumping:	Self-dumping	ABS Anti-lock Braking System:	ABS Anti-lock Braking System
Material:	Steel	Condition:	New
Use:	Truck Trailer	Main Beam:	500mm Height Q345b
Keywords:	Dump Tipper Semi Trailer	Brake System:	Dual Line Braking System
Landing Gear:	Standard 28ton	Function:	Stones And Sands
Product Name:	Dumper	Suspension:	Mechanical Suspension
Transport Package:	Container. Bulk Ship. RO-RO	Specification:	By The Customer Needs
Trademark:	Jinrui	Origin:	Shandong Province China
Supply Ability:	3000	Customization:	Available
After-sales Service:	1 Year	Warranty:	1 Year

Item	Specification
Product name	dumper
Size	1200026002880mm.
Body Sheet	Side wall thickness: 8mm, floor thickness: 6mm; Body material: wear resistant steel.
Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel, welded by automatic Submerged-Arc processes.
Axle	20T FU-WA brand axle
Tire	12.00R20
Rim	8.5-20
Braking system	2 line air braking system with air tank, WABCO emergency relay valve, braking chambers and mechanical slack adjusters.
Electrical system	24V, LED lights. 7 pin electrical connector. Parking, stop, reverse, number plate and indicator lights conform to European standard, rear front and side reflectors.
Shot blasting	Chassis is comletely shotblasted to SA 2.5 grade,and painted with first layer of international Zinc Epoxy primer(30 Microns DEF),second layer international high built polyurethane under coat(40 microns DFT),THIRD AND FORTH LAYERS INTERNATIONAL alkyd FINISH TOP coat.total 80-100 microns. high quality painting. the whole trailer waxed.
Landing gear	28T, two side operation.
Chamber	Double type
King pin	(2') 50# or (3.5') 90#
Cylinder	Side tipper 120
Spare tire carrier	CIMC standard
Tool box	CIMC standard
Color	According to customers' requirements and RAL color code.

Features: 1. A variety of types for you to choose: skeleton type/plate type/U type. 2. Axle 2/3/4/6 can be used for different road conditions. 3. Straight beam or gooseneck type optional. 4. Provide container twist locks. 5. After dumping, quick unloading, clean unloading. 6. Different lengths are optional. High fence up to 2000mm.7. Multiple ways to open doors.

1. How To Buy From Us ? How to Pay?

- quotation-offer-contract-1st payment-production-final payment-shipment-documentation;
TT/LC/Western Union/Credit Card

2. If Our Vehicle/Trailer Can Couple With Your Tractor Head ?

- 90% Of The Truck In The Market Can Coupling With Our Vehicle, As Howo, Shacman, Beiben, Volve...

- If Other Brand Truck Head, Please Inform Our Sales Manager Before Order Placing

3. Whats The Time For Delivery & Arrival ?

- If Standard Model We Have In Stock Can Ship It Out Within 10 Days After Payment.

- If It Belongs To Customize Series, Ordinary Cases In 15 Days Can Be Finished For Shipment.

- For Asian Countries, Ship Can Be Reached In 1-2 Weeks, If For African & Mid East & European Countries,

25 Workdays Will Be Achieved.

4. If We Can Provide Terms For Reducing Your Import Duties ?

- Yes, Please Contact With Us, We Are Nationalized Manufacture With Tax Reduction

1. Steel structure: The steel frame is made of first-class hot rolled or rolled steel plates, automatic welding of longitudinal beams, and advanced sanding and painting processes are used as preliminary treatment. 2. Different types of suspension are designed for various working conditions: bogie suspension; Air suspension; Mechanical suspension. 3. The lamp assembly adopts advanced LED lights, high quality PC and cast wiring harness of double circuit design. 4. Optional automatic tire inflation and pressure sensor system to improve safety and fuel economy. 5. The most advanced testing equipment: analyze the composition, hardness and phase of the metal to ensure the standard of processing materials; Check and modify weld defects, paint thickness and adhesion to ensure finished product quality.

Why choose us? We are the promoters of trucks We focus on manufacturing and sales We have a more professional design team to meet customer needs, make requirements, can be customized according to customer requirements. In short, the customer is the purpose of our service, does not affect the quality. All production according to customer requirements!!

Factory Price 5 Axle 100 Ton 80 Ton Cargo Trailer Van Box Curtain Side Dump Truck Trailer Van
