Product Details:
|
| Model NO.: | EHL9400ZHX | Shape: | Flatbed |
|---|---|---|---|
| Axle Number: | 3 | Tire Number: | 12 |
| Self-dumping: | Self-dumping | ABS Anti-lock Braking System: | ABS Anti-lock Braking System |
| Material: | Steel | Condition: | New |
| Transport Package: | Container. Bulk Ship. RO-RO | Specification: | By The Customer Needs |
| Trademark: | Jinrui | Origin: | Shandong Province China |
| Supply Ability: | 3000 | Customization: | Available |
| After-sales Service: | 1 Year | Warranty: | 1 Year |
| Name | 3/4/5/6 Axle Dump Semi Trailer | ||
| Overall Size | 9500*2550*3500mm, customization | ||
| Box Size | 9000*2550*1500mm, customization | ||
| Box Thickness | Bottom plate 8mm, side plate 6mm, customization | ||
| Hydraulic system | HYVA front lift, customization | ||
| Loading weight (KG) | 40-90Tons | ||
| Axle | 13T/16T/20T, ZHENGYANG/FUWA/BPW brand | ||
| Suspension system | Mechanical/Air suspension | ||
| Main beam | Q345, Beam height 500mm, top plate 16mm, bottom plate 18mm, middle plate 10mm. customization | ||
| Tires | 12R22.5 with 1 spare tyre Option:12.00R20 radial tyre; 315/80R22.5 diagonal tyre; 13R22.5 radial tyre | ||
| King pin | 3.6" (90mm) / 2" (50mm) | ||
| Spare wheel holder | 1 | ||
| Toolbox | 1 | ||
| Landing gear | Standard 28 Tons | ||
| Electrical system | Voltage: 24v Socket: 7-way (7-wire harness) Rear light with indicator, brake light and reflector, side light A standard 6-conductor cable | ||
| Side guard | Standard | ||
| Paint color | Custom (Polyester paint) | ||
| Packaging | Waxing before departure | ||
