Product Details:
|
| Tread: | 2240mm | Grade: | Heavy Duty |
|---|---|---|---|
| Types Of Suspension Systems: | Hydro-Pneumatic Suspension | Shape: | Van-type |
| Axle Number: | 2.3 | Tire Number: | 14 |
| Self-dumping: | Self-dumping | ABS Anti-lock Braking System: | No ABS Anti-lock Braking System |
| Material: | Iron | Condition: | New |
| Tire: | 12r22.5 | Landing Leg: | 28t, Two Speed, Manual |
| Axle: | 13t Axle | Size: | 13500X3000X1550 Mm |
| Product Name: | Low Bed Semi Trailer | Name: | Semi Trailer |
| Load: | 50 Tbelow | Transport Package: | Container. Bulk Ship. RO-RO |
| Specification: | Please Consult Customer Service | Trademark: | Jin Rui |
| Origin: | Liangshan, Shandong Province, China | HS Code: | 8716399000 |
| Supply Ability: | 500 Set/Sets Per Month | Customization: | Available |
| After-sales Service: | 3 Yearplease Consult Customer Service | Warranty: | 2 Year |
| LEAO Lowbed Lowboy Semi Trailer(Customerize and OEM Service Available) | |||
| Product Name | 2 axles lowbed semi trailer | 3 axles lowbed semi trailer | 4 axles lowbed semi trailer |
| Size(mm) | 12500*3000*1100 | 13000*3000*1100 | 14000*3000*1100 |
| Payload | 40000KG | 60000KG | 80000KG |
| Plate | 4mm checked plate | 4mm checked plate | 5mm checked plate |
| Axles | 2 * 13ton capacity | 3 * 13ton capacity | 4 * 13ton capacity |
| (Brand optional) | (Brand optional) | (Brand optional) | |
| Ladder | Hydraulic ladder or Mechanical spring ladder | ||
| Main beam | Height: 500mm, upper plate is 16mm, middle plate is 8mm, down plate is 18mm ; | ||
| Material is Q345B Steel. | |||
| Side beam | 250mm I beam; 20mm channel steel ( Material is Q235steel ). | ||
| Bottom Platform | 4mm thickness diamond steel plate | ||
| Suspension | Mechanical suspension (Air suspension optional) | ||
| Leaf spring | 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 | ||
| (specially intended for overseas markets) | |||
| Tire | 12R22.5 / 11.00R20 8pcs (Other size optional) | ||
| Rim | 9.00-22.5 / 11.00R20 8pcs (Other size optional) | ||
| Kin pin | 2''/3.5'' bolt type | ||
| Landing gear | 28 Ton two speed | ||
| Braking system | Double air chamber ,brake valve,45L air tanks ;ABS optional | ||
| Electrical | LED light , 7 ways ,24V | ||
| Accessory | One tooling box with a set of standard trailer tool | ||
| Painting | 1.Sand blasting processing clean rust. | ||
| 2.Coat of anticorrosive primer. | |||
| 3.Coats of finish urethane paint. | |||
| 4.Color as customer choice. | |||
| Other Descriptions | The cargo platform is lower than others, it is applicable for unsound road condition, and ensuring the stablenessof the transportation. | ||
| Usage | It is applicable for the transportations of the mechanical equipment, large objects, highway construction equipment, large tanks, power plant equipment or machine, and all sorts of steel products. | ||
| Other Specifications | It's concave structured with tyre appeared style, the height of the cargo's carrying platform from ground is 900mm, (ladders belong to optional components), with the overall height of 1710 mm. | ||
| Remark | We can design model according to client's requirement. | ||
Liangshan Hongxiang Vehicle Manufacturing Co., Ltd. is located at the foot of the famous waterside Liangshan Mountain, close to the 220 National Road and Beijing-Kowloon Railway, the scenery is pleasant and the traffic is very convenient.
Contact Person: Mr. Xie
Tel: +86 13165184599
